2N1168 PNP 50V 5A Germanium TO3 Mount Transistor 45W

2N1168 PNP 50V Germanium Transistor

• Material of Transistor: Ge
     Polarity: PNP
     Maximum Collector Power Dissipation (Pc): 45 W
     Maximum Collector-Base Voltage |Vcb|: 50 V
     Maximum Collector-Emitter Voltage |Vce|: 30 V
     Maximum Emitter-Base Voltage |Veb|: 20 V
     Maximum Collector Current |Ic max|: 5 A
     Max. Operating Junction Temperature (Tj): 95 °C
     Transition Frequency (ft): 0.1 MHz
     Forward Current Transfer Ratio (hFE), MIN: 70

• TO3 case
