2N3441 NPN 160V 25W Power Transistor

2N3441 NPN Transistor

   Material of Transistor: Si
   Polarity: NPN
   Maximum Collector Power Dissipation (Pc): 25 W
   Maximum Collector-Base Voltage |Vcb|: 160 V
   Maximum Collector-Emitter Voltage |Vce|: 140 V
   Maximum Emitter-Base Voltage |Veb|: 7 V
   Maximum Collector Current |Ic max|: 3 A
   Max. Operating Junction Temperature (Tj): 200 °C
   Transition Frequency (ft): 0.2 MHz
   Forward Current Transfer Ratio (hFE), MIN: 25
