2305 Low Thermal EMF Spade Lug

2305 Low Thermal EMF Spade Lug, Gold-Plated

FEATURES:

• To ensure accurate low voltage or high resistance precision measurements, Pomona’s durable Model 2305 features heavy duty construction with a gold plated tellurium copper base.
• The tellurium copper/gold material combination offers superior conductivity and low oxide build-up and minimizes the thermoelectric effect, thus ensuring accurate readings in the nano-volt or 109 ohmic range.
• The spade lug attaches to shunt terminals, standard binding posts or ¼” screws. For meter attachment, the
• Model 2305 is designed with an insulated standard banana jack which will interface to Pomona’s Low EMF Retractable Sheath Banana Plug Cord Model 5291.

MATERIALS:

• Spade Lug Body – Tellurium Copper, Alloy 145, Gold Plated per MIL-G-45204
• Banana Jack – Tellurium Copper, Alloy 145, Gold Plated per MIL-G-45204
• Insulation – ABS Molded to Banana Jack and Spade Lug Body
• Colors: Black and Red,
• Marking: “Pomona Electronics, Calif.”

RATINGS:

• Operating Temperature: +50°C (+122°F)
• Operating Voltage – 5000 VDC
• Current: 15 Amperes
