96-0001 McGill 19A Single-Pole 2-Circuit Toggle Switch

96-0001 McGill 19A Single-Pole 2-Circuit Toggle Switch

• Off-On-On
• 19 A 125 V AC
• 4 A 125 V AC, center position
• 15 A 125 V AC end position
• Single pole, two circuit
• Underwnters Laboratones, Inc., Listed
• C.S.A. Approved
• No. 96-0001 series is the same basic design as the No. 90 series with ratings given and available for 2-circuit control.
• Operating sequence : off-on (4 A) - One and two (15 A) typical use on projectors to actuate fan and motor with first operation and fan, motor and lamp with second operation.
• Switch Box 1
